Traditional House
A house you can see before it is built
The Traditional House is a house we drew to show how we work: painted brick, a columned portico between two gabled wings, a two-story hall behind the doors, and behind the house a pool under a roof of glass. Every wall is drawn to a dimension, checked the way a building is checked, and then built in three dimensions from the same drawings.
A design illustration, not a photograph of a house.
From above
The house, opened floor by floor
Scroll, and a level plane comes down through the Traditional House from the ridge to the lower level, while the day goes from morning to night. Where the plane meets a wall the wall shows solid, as it does on an architect's section. Every room is where the drawings put it, and the ones with a page of their own open from their names.
9:10 am
The roof
Morning. The hipped roof of the main block between its two chimneys, the gables of the two wings, each with a dormer, and of the great room behind; the flat roof of the breakfast room with its five skylights; and the pediment of the portico over the front door.
10:50 am
The upper floor
Late morning, with the roof and the ceilings lifted off. Four bedrooms in the main block, two each side of the gallery that looks down into the round entrance hall on one side and the great room on the other. In the roof of the east wing, a fifth bedroom and a long recreation room over the garage; the west wing has no upper floor, its bedroom and bath open to the roof.
2:45 pm
The main floor
Early afternoon. The round entrance hall with a stair curving up each side, the living room and the dining room to either hand, and behind them the great room, the kitchen and the breakfast room. The primary suite has the west wing to itself; the garage, the back stair and a guest bedroom have the east.
8:35 pm
The lower level
After dark, with the house lifted away and the lamps on below ground: the lounge and its bar, the games room under the great room, the theater, a gym and the wine cellar, and a recreation room and a guest suite under the west wing.
- Lounge and bar
- Games room
- Theater
- Gym
- Mechanical room
- Recreation room
- Guest suite
The day
One day, from morning to dusk
The Traditional House on its lot through a single day: sun on the brick in the morning, long shadows across the lawn in the afternoon, and the lamps coming on at dusk. These are three moments of it.
The tour
From the roof to the lower level in one scroll
The roof, every room with a page of its own in the order you would come to it, and the garden on the way, each at its own hour of the day, with the things in it one at a time.
Take the whole tourThe house in figures
Read from the specification the model is generated from, so the figures and the picture cannot disagree.
Entrance elevation, generated from the specification.
- Living area
- 13,192 sq ftOn three levels: main 5,260, upper 3,140, lower 4,792.
- Entrance front
- 120 ftThe house is 64 ft deep.
- Height
- 36 ft 2 inTo the main ridge. The eaves of the main block are at 22 ft, those of the wings at 14 ft.
- Portico
- 24 ftFour columns, each 18 ft 11 in tall.
- Main-floor ceilings
- 10 ft
- Garage
- Three bays936 sq ft, entered from the side court.
- Pool
- 48 × 24 ftUnder a glass roof of 76 × 40 ft, with an island in the middle for a bar.
- Lot
- 1.83 acresWith a 78 × 36 ft court marked for tennis and basketball, inside a 6 ft fence.
The plans
Three levels. The entrance hall is a round room two stories high with a stair curving up each side; behind it the great room rises through both floors to face the garden. The primary suite has the west wing of the main floor to itself, its bedroom and its bath open to the roof.
Main level Entrance hall (22 ft across) · Living room (22 × 17 ft) · East hall (6 × 16 ft) · Dining room (16 × 16 ft) · Kitchen (22 × 13 ft) · Gallery hall (24 × 10 ft) · Study (16 × 11 ft) · Study gallery (22 × 6 ft) · Great room (24 × 28 ft) · Breakfast room (22 × 16 ft) · Primary bath (26 × 17 ft) · Primary bedroom (26 × 26 ft) · Garage (26 × 36 ft) · Guest bedroom (20 × 14 ft)
Upper level Gallery (24 × 10 ft) · West hall (5 × 20 ft) · Bedroom 2 (22 × 14 ft) · Bedroom 3 (17 × 14 ft) · Upper hall (22 × 6 ft) · Bedroom 4 (16 × 14 ft) · Bedroom 5 (16 × 14 ft) · Bedroom 6 (26 × 12 ft) · Recreation room (26 × 32 ft)
Lower level Lower hall (22 × 18 ft) · Lounge and bar (24 × 34 ft) · Games room (24 × 28 ft) · Theater (22 × 17 ft) · Store (14 × 11 ft) · West hall (22 × 6 ft) · Wine cellar (6 × 16 ft) · Gym (16 × 16 ft) · Mechanical room (22 × 16 ft) · Recreation room (26 × 34 ft) · Guest suite (16 × 22 ft)
The stairs in the entrance hall climb 19 risers of 7.26 in, with treads 10.56 in deep on the walking line. North is up; the entrance front is at the foot of each sheet.
